Victron Hybrid Inverter Charger with Solar MPPT Multi RS Solar 48v 6000Va 100 amp 450v/100amp, Car Parts

Car Accessories

Victron Hybrid Inverter Charger with Solar MPPT Multi RS Solar 48v 6000Va 100 amp 450v/100amp Multi RS Solar 48/6000 48 V 6 kVA Inverter/Charger 450 VDC 4 kWp PV input. Light Weight  High Frequency Technology  Quiet Running Combination of an inverter, AC charger, and Solar MPPT The inverter produces a perfect sine wave, and able to supply high powered appliances. It is also bi-directional, charging the battery when excess solar power or AC supply is available, or converting from the battery when it is needed. Wide MPPT voltage range 80 ? 450 VDC, with a 120 VDC PV startup voltage. Light weight, efficient and quiet, Thanks to the high frequency technology and a new design this powerful inverter weighs only 11 kg. In addition to this it has an excellent efficiency, low standby power, and a very quiet operation. Display, Bluetooth and VictronConnect app The display reads battery, inverter and solar parameters. The same parameters can be accessed with a smartphone or other Bluetooth enabled device, using the VictronConnect app. Extendable PV capacity, both AC-coupled and DC-coupled The integrated 4 kWp PV capacity can be extended by adding Solar Chargers to the system, for example our Smart Solar Charger range, including the Smart Solar RS models. When connected in a VE.Can network, all battery charging will operate synchronously and be coordinated. Alternatively, the PV capacity can be extended by installing AC PV Inverters, of which the output power will be automatically controlled by the integrated Frequency Shift Power Control. Communication ports VE.Can connection to a GX device for system monitoring, data logging, and remote firmware updates. VE.Direct connection to a GlobalLink 520 for remote data monitoring. I/O Connections Programmable Relay, temperature sensor and voltage sensor connections. The remote input can also be configured to accept the Victron smallBMS. The Multi RS Solar 48/6000 is a 48V 6kVA Inverter/Charger with 450VDC 4kWp PV input.

More information

More information

Table of Contents

• Why it matters
• Features & benefits
• Key specifications
• Usage & maintenance
• Frequently Asked Questions

Why it matters

The Victron Hybrid Inverter Charger with Solar MPPT Multi RS Solar is a versatile solution for those looking to harness solar energy efficiently. It combines an inverter, AC charger, and solar MPPT in one unit, making it ideal for both residential and commercial applications. This device not only provides power but also optimizes energy use, ensuring that you can rely on renewable sources effectively.

Quick overview

• Inverter/Charger: Combines multiple functionalities.
• Solar MPPT: Maximizes solar energy capture.
• Lightweight: Weighs only 11 kg.
• High efficiency: Low standby power and quiet operation.

Useful details

With a wide MPPT voltage range of 80 to 450 VDC and a startup voltage of 120 VDC, this inverter is designed to accommodate various solar panel setups. Its bi-directional capability allows it to charge batteries when excess power is available, ensuring that energy is used efficiently.

Features & benefits

• Perfect Sine Wave Output: Ideal for high-powered appliances, ensuring they operate smoothly.
• Bluetooth Connectivity: Monitor and control the inverter using the VictronConnect app on your smartphone.
• Extendable PV Capacity: Easily add more solar chargers or AC PV inverters to increase capacity.
• VE.Can and VE.Direct Connections: Enables system monitoring and remote firmware updates for enhanced functionality.
• Programmable Relay: Offers flexibility in system configuration and monitoring.

Key specifications

• Model: Multi RS Solar 48/6000
• Input Voltage: 450 VDC
• Output Power: 6 kVA
• Battery Voltage: 48 V
• PV Input: 4 kWp
• Weight: 11 kg
• Efficiency: High efficiency with low standby power

Usage & maintenance

To ensure optimal performance of the Victron Hybrid Inverter Charger, regular monitoring and maintenance are recommended. Here are some practical tips:

Practical tips

• Check connections regularly to ensure they are secure and free from corrosion.
• Use the VictronConnect app to monitor performance and make adjustments as needed.
• Keep the inverter in a well-ventilated area to prevent overheating.
• Regularly update firmware through the VE.Direct connection for improved functionality.

Frequently Asked Questions

• What is the maximum PV input voltage? 450 VDC.
• Can I monitor the inverter remotely? Yes, using the VictronConnect app via Bluetooth.
• Is it suitable for high-powered appliances? Yes, it produces a perfect sine wave output.
• How much does it weigh? The inverter weighs 11 kg.
• Can I extend the PV capacity? Yes, by adding more solar chargers or AC PV inverters.
